Free Download Autocad Electrical 2024 A Tutorial Series
Published 2/2024
MP4 | Video: h264, 1920x1080 | Audio: AAC, 44.1 KHz
Language: English | Size: 4.81 GB | Duration: 5h 16m
For Electrical Control Designers
What you'll learn
You will navigate and familiarize yourself with the software's user-friendly interface, tools, and functionalities
You will learn to create, edit, and manage electrical schematics with precision and clarity
You will learn the art of designing intricate panel layouts for various electrical projects
This course also covers a wide range of tools and features such as Circuit Builder, PLC module insertion, Report generation, Title blocks & Templates, and so on
Requirements
The instructor starts right from the basics so there are no prerequisites. However, knowledge of AutoCAD is an added advantage
Description
AutoCAD Electrical is the software of the AutoCAD suite which is intended to help control designers with the creation and modification of control systems. This software has extended features to automate control engineering tasks, such as building circuits, numbering wires, and creating bills.For electrical engineers it is good for making circuit layout to power plant layout. This module includes drafting of electrical schematic diagrams, panel layouts, automatic report generation, PLC I/O drawing for spreadsheet, and so on.This course is basically designed to assist the engineering students and the practicing designers. Keeping in view the varied requirements of the students, this course covers a wide range of tools and features such as schematic drawings, Circuit Builder, panel drawings, parametric and non-parametric PLC modules, stand-alone PLC I/O points, ladder diagrams, point-to-point wiring diagrams, report generation, creation of symbols, and so on. On the completion of this course, students will be able to create electrical drawings easily and effectively.Salient Features of this Course:A tutorial based course consisting of 48 video lectures that are organized in a pedagogical sequence.Covers all important AutoCAD Electrical commands and tools.Step-by-step instructions to guide the users through the learning process. Self Evaluation TestsCertificate of Completion
Overview
Section 1: Introduction
Lecture 1 Overview of AutoCAD Electrical 2024_Interface
Lecture 2 Customizing AutoCAD Electrical Interface
Section 2: Working with Project Manager
Lecture 3 Creating a New Project and Adding a New Drawing to it
Lecture 4 2. Managing Drawings and Configuring the Drawing List Display
Lecture 5 Copying a Project, Exception List and Settings Compare
Lecture 6 Surfing a Component and Extracting Component and Connection Information
Section 3: Working with Wires
Lecture 7 Inserting, Trimming Wire, and Deleting Wire Number
Lecture 8 Creating a New Wire Type and Changing the Wire Type of an Existing Wire
Lecture 9 Inserting and Fixing Wire Numbers, Inserting Wire Color Gauge labels
Lecture 10 Showing and Editing Wire Sequence
Section 4: Working with Ladders
Lecture 11 Inserting a SIngle Phase Ladder
Lecture 12 Inserting 3 Phase Ladder and Multiple Wire Bus
Lecture 13 Stretching and Revising the Ladder
Lecture 14 Setting the Format for Reference Numbers and Inserting X-Y Grid Labels
Section 5: Schematic Component Insertion
Lecture 15 Inserting a Ladder and Schematic Components and Description
Lecture 16 Editing a Component, Adding Wire, and Trimming Rung
Lecture 17 Swapping a Component and Changing the Symbol Library
Lecture 18 Swapping a Component and Creating Project Specific Catalog Database
Section 6: Schematic Component Editing
Lecture 19 Copying, Moving, and Aligning components
Lecture 20 Auditing a Drawing
Lecture 21 Inserting Components, Copying Catalog and Location Data
Lecture 22 Updating the Drawings
Section 7: Connectors. Point to Point Wiring Diagrams, and Circuits
Lecture 23 Creating a Point to Point Wiring Diagram using Connectors
Lecture 24 Creating a Point to Point Wiring Diagram using Connectors and Splices
Lecture 25 Inserting Saved Circuit, Copying Circuit, and Saving Circuit to an ICON Menu
Lecture 26 Configuring a One Line Motor Circuit
Lecture 27 Inserting Saved Circuit and Saving a Circuit as a Wblocked Circuit
Section 8: Panel Layouts
Lecture 28 Extracting Schematic Component List and Inserting Panel Footprints from the List
Lecture 29 Editing the Footprints and Adding Balloons to the Footprints
Lecture 30 Inserting Footprints Manually and Making Xdata Visible for the Footprints
Lecture 31 Inserting Footprints using the User Defined List Tool and Adding a New Library
Lecture 32 Adding New Footprint Record to the Footprint User Defined List
Section 9: Reports Generation
Lecture 33 Generating Schematic BOM and Component Report
Lecture 34 Generating Panel Nameplate and Panel Component Report
Lecture 35 Generating Cumulative Report
Section 10: PLC Modules
Lecture 36 Inserting Parametric PLC Module
Lecture 37 Creating a New PLC Module using the PLC Databse File Editor Tool
Lecture 38 Creating PLC IO Wiring Diagrams
Section 11: Terminals
Lecture 39 Inserting Terminal Symbol and Entering Information
Lecture 40 Inserting DIN Rail and Terminal Strip
Section 12: Project and Drawing Properties, Title blocks and Templates
Lecture 41 Changing Drawing Properties of Wire Numbers and Updating Wire Numbers
Lecture 42 Changing Project Properties of Active Project
Lecture 43 Creating a New Template and Creating a New Drawing using the New Template
Lecture 44 Creating a Project Description Line File and Updating the Title Block
Section 13: Creating Symbols and Using Miscellaneous Tools
Lecture 45 Creating a Symbol with Attributes and Saving and Inserting it
Lecture 46 Adding Customized Symbol to an Icon Menu
Lecture 47 Exporting Data from a Drawing, Modifying it, and Importing it Back to a Drawing
Lecture 48 Marking and verifying a drawing
Degree/Diploma holders and Professionals in electrical field
